IBM X3650 M4 (2) E5-2680 2.70GHz 8C CPU 192GB RAM (3)x 146GB 15K HDD Server

For Equipment sold by IGS to any end-user, IGS warrants the Equipment will be free from defects in material and workmanship for a period of one year from and after the date of purchase when utilized for its normal and intended use in accordance with manufacturer guidelines. For more information on returns and our return process please check our policies & returns page.

Feature:

IBM System x3650 M4 Server

Form Factor:

2U

Processors:

Up to two Intel Xeon processors E5-2600 v2 product family CPUs with:

12C (up to 2.7GHz)

10C (up to 3.0GHz)

8C (up to 3.3GHz)

6C (up to 3.5GHz)

4C (up to 3.5GHz)

Two QPI links up to 8.0 GT/s each.

Up to 1866MHz memory speed.

Up to 30MB L3 cache.

Chipset:

Intel C602J

Memory:

Up to 24 DIMM sockets (12 DIMMs per processor)

RDIMMs, UDIMMs, HyperCloud DIMMs, and LRDIMMs (Load Reduced DIMMs) are supported, but memory types cannot be intermixed.

Memory speed up to 1866 MHz.

Memory Maximums:

With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors

With UDIMMs: Up to 128 GB with 16x 8 GB UDIMMs and two processors

With HyperCloud DIMMs: Up to 768 GB with 24x 32 GB DIMMs and two processors

With LRDIMMs: Up to 768 GB with 24x 32 GB LRDIMMs and two processors

Memory Protection:

ECC, Chipkill, memory mirroring, and memory rank sparing.

Disk Drive Bays:

Up to 32 1.8" SSD bays

Up to 16 2.5" hot-swap SAS/SATA bays

Up to six 3.5" hot-swap SAS/SATA bays

Up to eight 2.5" Simple Swap SATA bays

Up to six 3.5" Simple Swap SATA bays

Maximum Internal Storage:

Up to 28.8 TB with 1.8 TB 2.5" SAS HDDs

Up to 16 TB with 1 TB 2.5" NL SAS/SATA HDDs

Up to 25.6 TB with 800 GB 1.8" SATA SSDs

Up to 25.6 TB with 1.6 TB 2.5" SAS/SATA SSDs

Up to 36 TB with 6 TB 3.5" NL SAS/SATA HDDs

Intermix of SAS/SATA is supported

RAID Support:

6GB SAS/SATA:

RAID 0, 1, 10 with integrated M5110e or optional M5110; optional upgrades to RAID 5, 50 are available (zero-cache; 512 MB battery-backed cache; 512 MB or 1 GB flash-backed cache). Optional upgrade to RAID 6, 60 is available for M5110e or M5110 with 512 MB or 1 GB cache upgrades.

12GB SAS/SATA:

RAID 0, 1, 10 with optional M5210; optional upgrades to RAID 5, 50 are available (zero-cache; 1 GB non-backed cache; 1 GB or 2 GB flash-backed cache). Optional upgrade to RAID 6, 60 is available for M5210 with 1 GB or 2 GB cache upgrades.

Optical Drive Bays:

One bay for optional DVD-ROM or Multi-burner drive

Tape Drive Bays:

Optional Tape Enablement Kit is available to support one DDS5, DDS6, or RDX internal USB tape drive.

Network Interfaces:

Four integrated Gigabit Ethernet 1000BASE-T ports (RJ-45); two embedded 10 Gb Ethernet ports (10GBASE-T RJ-45 or 10GBASE-SR SFP+ based) on optional 10 Gb Ethernet mezzanine card (does not consume PCIe slot).

PCI-Expansion Slots:

Up to six slots depending on the riser cards installed. The slots are as follows:

• Slot 1: PCIe 3.0 x8; full-height, full-length
• Slot 2: PCIe 3.0 x8; full-height, half-length

• Slot 3: PCIe 3.0 x8; full-height, half-length
• Slot 4: Optional, requires second processor and second riser card
• Slot 5: Optional, requires second processor and second riser card
• Slot 6: Optional, requires second processor and second riser card

Optional riser cards available with PCIe x8 or PCIe x16 or PCI-X slots.

Ports:

Two USB 2.0 and one DB-15 video on front. Four USB 2.0, one DB-15 video, one DB-9 serial, one RJ-45 systems management, four RJ-45 GbE network ports, two optional RJ-45 or SFP+ 10 GbE network ports on rear. Two internal USB ports (for embedded hypervisor and internal tape drive).

Cooling:

Calibrated Vectored Cooling with up to four redundant hot swap fans (three standard, additional fan with second processor or with the x3650 M4 Thermal Solution Kit); two fan zones with N+1 fan design; each fan has two motors.

Power Supply:

Up to two redundant hot-swap 550 W AC or 750 W AC or 900 W AC power supplies (all 80 PLUS Platinum certification), or -48V 750 W DC power supply options.

Video:

Matrox G200eR2 with 16 MB memory integrated into the IMM2. Maximum resolution is 1600x1200 at 75 Hz with 16 M colors.

Hot-Swap Parts:

Hard drives, power supplies and fans.

Systems Management:

UEFI, Integrated Management Module II (IMM2), Predictive Failure Analysis, Light Path Diagnostics, Automatic Server Restart, IBM Systems Director and Active Energy Manager, ServerGuide. Optional Integrated Management Module Advanced Upgrade software feature for remote presence.

Security Features:

Power-on password, administrator's password, Trusted Platform Module (TPM).

Operating Systems:

Microsoft Windows Server 2012 R2, 2012, 2008 R2 and 2008

Red Hat Enterprise Linux (RHEL) 5, 6, and 7

SUSE Linux Enterprise Server (SLES) 10, 11, and 12

VMware vSphere (ESXi) 5.0, 5.1, 5.5, and 6.0.

Dimensions:

Height: 86 mm (3.4 in), width: 445 mm (17.5 in), depth: 746 mm (29.4 in)

Weight:

Minimum configuration: 25 kg (55 lb), maximum: 30 kg (65 lb)

Some server products say CTO in the name, and this acronym means Configure-to-Order; these servers have no CPU, memory, power, HDD, or rails. If you need a custom-configured server, chat with us now. We are happy to help. You can also book an online appointment with one of our product specialists to discuss your needs.
